S80|客人，您的S80 POS机可以升级啦~

1.关机

2.开机同时不停的按menu键直到屏幕上出现三个选项

3.选择3. Remote Download

4a如果机器出现NEW/DUPLICATE/RESUME download,这里选择 1.NEW download.

5a.选择 2.TCP

6a.输入IP 地址：50.79.90.190

7a.输入port:8001

8a.机器会出现 "Enable DHCP", 选择 1 YES

9a.输入Terminal ID: 80000001

10a.再机器下载完成后，重启机器

4b.如果机器出现另一个页面 PROTIMS/UNIONPAY, 选择 1.PROTIMS.

5b. 选择2.TCP/IP

6b. 输入Terminal ID: 80808082

7b. 输入 IP地址：50.79.90.190

8b. 输入port：8001

9b. 机器会出现 Auto get local IP address,选择 1 Yes.

10b. 当机器下载完，重复一次4a - 10a的步骤。

Please follow the steps to upgrade.

1. Power off the terminal.

2. Power the terminal back on and  then keep hitting ‘Menu’ button till you see a new menu with 3 options..

3. A new menu will appear, select 3. Remote Download

4a. If the terminal shows a menu with NEW/DUPLICATE/RESUME download, select the NEW download option.

5a. Select TCP

6a. Enter Remote IP address: 50.79.90.190

7a. Enter Port: 8001

8a. Terminal will display "Enable DHCP", select 1 for YES

9a. Enter Terminal ID: 80000001

10a. After downloading is completed, reboot the terminal.

4b. If the terminal displays another menu with PROTIMS/UNIONPAY, select PROTIMS.

5b. Select TCP/IP

6b. Enter Terminal ID: 80808082

7b. Enter Remote IP address: 50.79.90.190

8b. Enter Port: 8001

9b. Terminal will display Auto get local IP address, select 1 for Yes.

10b. Once the download is complete, REPEAT the steps from 4a - 10a.
