【应知应会】使用kfed运维兵器修复ASM磁盘和磁盘组

【应知应会】使用kfed运维兵器修复ASM磁盘和磁盘组 数据库运维之道
2024-03-28
1
导读：数据库的ASM磁盘或ASM磁盘组不小心被人为误删除从而导致磁盘组无法挂载，DBA需要将磁盘组挂载起来。通过实验再次模拟故障环境，详细分解每个操作步骤，避免下次继续踩坑从而提升运维处置效率。
欢迎关注“数据库运维之道”公众号，一起学习数据库技术! 本期将为大家分享“使用kfed运维兵器修复ASM磁盘和磁盘组” 的运维技能。

关键词：ORA-15053、ORA-15027、ORA-15040、ORA-01187、kfed repair、kfed merge、kfed read、strace

数据库的ASM磁盘或ASM磁盘组不小心被人为误删除从而导致磁盘组无法挂载，DBA需要将磁盘组挂载起来。通过实验再次模拟故障环境，详细分解每个操作步骤，避免下次继续踩坑从而提升运维处置效率。

场景描述：假设ASM磁盘组被删除，我们将如何进行快速恢复呢？

模拟环境：两个节点的RAC集群、数据库名YWZD、ASM磁盘组名称YWZD、测试ASM磁盘名称YWZD1。

实验步骤：

1、查看ASM磁盘的名称、路径和状态信息；





    col path for a50set pagesize 100set linesize 1000select name,path,header_status from v$asm_disk where group_number = (select group_number from v$asm_diskgroupwhere name='YWZD');-->输入ASM磁盘组名称NAME                   PATH                          HEADER_STATU------------------------------ -------------------------------------------------- ------------YWZD_0000               /dev/oracleasm/disks/YWZD1              MEMBERMEMBER表示ASM磁盘是磁盘组的成员。
2、创建测试表空间和测试表；




    create tablespace ywzd datafile '+YWZD' size 100m;create table ywzd as select * from dba_tables;select count(*) from ywzd;  COUNT(*)----------      1884
3、删除ASM磁盘组，会报ORA-15053错误，即磁盘组存在文件；




    --删除ASM磁盘组su - grid$sqlplus / as sysasm
SQL> drop diskgroup ywzd;drop diskgroup ywzd*ERROR at line 1:ORA-15039: diskgroup not droppedORA-15053: diskgroup "YWZD" contains existing files
--错误码具体说明$oerr ora 1505315053, 00000, "diskgroup \"%s\" contains existing files"// *Cause:  An attempt was made to drop a diskgroup that still contains//          existing files.// *Action: Specify the INCLUDING CONTENTS option to drop the diskgroup//          and all of its existing files.//
4、根据上述方案，再次删除ASM磁盘组并加INCLUDING CONTENTS参数。但是出现ORA-15027错误，即磁盘组被实例占用无法dismount。




    --删除ASM磁盘组SQL> drop diskgroup ywzd including contents;drop diskgroup ywzd including contents*ERROR at line 1:ORA-15039: diskgroup not droppedORA-15027: active use of diskgroup "YWZD" precludes its dismount
--错误码具体说明$oerr ora 1502715027, 00000, "active use of diskgroup \"%s\" precludes its dismount"// *Cause:  An ALTER DISKGROUP ... DISMOUNT command specified a diskgroup //          which had clients with open files in the diskgroup. Diskgroups //          cannot be dismounted until all open files in the diskgroup //          are closed. // *Action: Stop all clients that are using this diskgroup and retry //          the ALTER DISKGROUP ... DISMOUNT command.  Query the V$ASM_CLIENT//          fixed view in an ASM instance or use ASMCMD LSOF to list active//          clients.//
--查看占用磁盘组的实例名select instance_name,db_name,status from GV$ASM_CLIENT where group_number = (select group_number from v$asm_diskgroup where name='YWZD');  -->>输入磁盘组名称INSTANCE_NAME               DB_NAME    STATUS------------------------------ -------- ------------+ASM1                   ywzd CONNECTED+ASM2                   ywzd CONNECTED
--或者使用lsof命令查看$asmcmdASMCMD> lsofDB_Name   Instance_Name  Path
ywzd  ywzd1      +YWZD/ywzd/DATAFILE/ywzd.257.1164789351            ywzd  ywzd1      +YWZD/ywzd_block_track.log
5、备份ASM磁盘头数据后，再执行删除，方便后面对比分析及恢复。
--备份磁盘头信息kfed read /dev/oracleasm/disks/YWZD1        >/tmp/YWZD1-0-0-B  磁盘头信息备份kfed read /dev/oracleasm/disks/YWZD1 blkn=1 >/tmp/YWZD1-0-1-B  对块号为1备份kfed read /dev/oracleasm/disks/YWZD1 aun=1  >/tmp/YWZD1-1-0-B  对aun为1备份
--关闭数据库实例$srvctl stop database -d ywzd
 --切换到grid用户，先把其中一个节点的磁盘组DISMOUNT，否则会出现以下错误。SQL> drop diskgroup ywzd including contents;drop diskgroup ywzd including contents*ERROR at line 1:ORA-15039: diskgroup not droppedORA-15073: diskgroup YWZD is mounted by another ASM instance
--成功删除SQL> drop diskgroup ywzd including contents;Diskgroup dropped.
‍
6、手动再拉起磁盘组，出现ORA-15040错误，即磁盘组不完整错误。




    --Mount磁盘组，提示磁盘组不完整SQL> alter diskgroup ywzd mount;alter diskgroup ywzd mount*ERROR at line 1:ORA-15032: not all alterations performedORA-15017: diskgroup "YWZD" cannot be mountedORA-15040: diskgroup is incomplete
--ASM实例日志，显示挂载失败2024-03-28T12:44:58.456141+08:00SQL> alter diskgroup ywzd mount 2024-03-28T12:44:58.461584+08:00NOTE: cache registered group YWZD 8/0x4C149EB9NOTE: cache began mount (first) of group YWZD 8/0x4C149EB92024-03-28T12:44:58.518360+08:00ERROR: no read quorum in group: required 2, found 0 disks2024-03-28T12:44:58.518657+08:00NOTE: cache dismounting (clean) group 8/0x4C149EB9 (YWZD)NOTE: messaging CKPT to quiesce pins Unix process pid: 29396, image: oracle@hlw3-db11 (TNS V1-V3)NOTE: dbwr not being msg'd to dismountNOTE: LGWR not being messaged to dismountNOTE: cache dismounted group 8/0x4C149EB9 (YWZD)NOTE: cache ending mount (fail) of group YWZD number=8 incarn=0x4c149eb9NOTE: cache deleting context for group YWZD 8/0x4c149eb92024-03-28T12:44:58.534982+08:00GMON dismounting group 8 at 26996 for pid 34, osid 293962024-03-28T12:44:58.536694+08:00ERROR: diskgroup YWZD was not mountedORA-15032: not all alterations performedORA-15017: diskgroup "YWZD" cannot be mountedORA-15040: diskgroup is incomplete
2024-03-28T12:44:58.543094+08:00ERROR: alter diskgroup ywzd mount
--错误码具体信息$oerr ora 1504015040, 00000, "diskgroup is incomplete"// *Cause:  Some of the disks comprising a diskgroup were not present.// *Action: Check the hardware to ensure that all disks are functional. Also//          check that the setting of the ASM_DISKSTRING initialization //          parameter has not changed.  Alternatively, for normal or high//          redundancy diskgroups, use MOUNT FORCE to offline missing disks//          as part of mounting the diskgroup.//
7、使用kfed再次备份下磁盘头数据，然后再进行删除前后对比。




    --备份磁盘头数据kfed read /dev/oracleasm/disks/YWZD1        >/tmp/YWZD1-0-0-Akfed read /dev/oracleasm/disks/YWZD1 blkn=1 >/tmp/YWZD1-0-1-Akfed read /dev/oracleasm/disks/YWZD1 aun=1  >/tmp/YWZD1-1-0-A
--通过diff命令进行对比diff /tmp/YWZD1-0-0-B /tmp/YWZD1-0-0-A
8、比较两个文件的差异信息，其中带有“!”符号的记录表示前后有差异。可以看到磁盘头状态从KFDHDR_MEMBER变成KFDHDR_FORMER。
命令一：$ diff -C 1 /tmp/YWZD1-0-0-B /tmp/YWZD1-0-0-A|grep "kfdhdb.hdrsts"*** /tmp/YWZD1-0-0-B    2024-03-28 12:23:29.022209374 +0800--- /tmp/YWZD1-0-0-A    2024-03-28 12:56:31.268409902 +0800****************** 21,23 ****  kfdhdb.grptyp:                        1 ; 0x026: KFDGTP_EXTERNAL! kfdhdb.hdrsts:                        3 ; 0x027: KFDHDR_MEMBER  kfdhdb.dskname:               YWZD_0000 ; 0x028: length=9--- 21,23 ----  kfdhdb.grptyp:                        1 ; 0x026: KFDGTP_EXTERNAL! kfdhdb.hdrsts:                        4 ; 0x027: KFDHDR_FORMER  kfdhdb.dskname:               YWZD_0000 ; 0x028: length=9***************  命令二：$diff -y /tmp/YWZD1-0-0-B /tmp/YWZD1-0-0-A|grep "|"kfdhdb.hdrsts:                        3 ; 0x027: KFDHDR_MEMBE |    kfdhdb.hdrsts:                        4 ; 0x027: KFDHDR_FORME
‍
9、核实上述的对比信息后，修改备份文件中的磁盘头状态参数kfdhdb.hdrsts，并将修改的内容合并到磁盘头。
--修改/tmp/YWZD1-0-0-A文件kfdhdb.hdrsts:即状态值从4改为3，状态名称从KFDHDR_FORMER改为KFDHDR_MEMBER
--合并修改结果kfed merge /dev/oracleasm/disks/YWZD1 text=/tmp/YWZD1-0-0-A
10、最后把磁盘组挂载起来，并进行数据验证。
--核实磁盘状态是否为MEMBERselect name,path,header_status from v$asm_disk where group_number = (select group_number from v$asm_diskgroupwhere name='YWZD');-->输入ASM磁盘组名称
--挂载磁盘组SQL> alter diskgroup ywzd mount;Diskgroup altered.
--启动数据库，并验证数据select count(*) from ywzd;
ASM磁盘组挂载成功！
实验证明：当磁盘组被误删除后，可以通过kfed进行完美恢复。
场景描述：假设执行oracleasm deletedisks 命令删除ASM磁盘，我们将如何进行快速恢复呢？
模拟环境：两个节点的RAC集群、数据库名YWZD、ASM磁盘组名称YWZD、测试ASM磁盘名称YWZD1。
实验步骤：
1、确认数据文件状态信息；




    --数据文件状态可用col file_name for a60set linesize 1000select file_name ,status from dba_data_files where file_name like '+YWZD%';FILE_NAME                             STATUS------------------------------------------------------------ ---------+YWZD/ywzd/DATAFILE/ywzd.257.1164789351             AVAILABLE
--ASM磁盘可识别$ oracleasm listdisks | grep YWZDYWZD1
2、先备份ASM磁盘头数据，再执行删除ASM盘，方便后面对比分析或恢复使用。




    --备份磁盘头信息kfed read /dev/oracleasm/disks/YWZD1        >/tmp/YWZD11-0-0-Bkfed read /dev/oracleasm/disks/YWZD1 blkn=1 >/tmp/YWZD11-0-1-Bkfed read /dev/oracleasm/disks/YWZD1 aun=1  >/tmp/YWZD11-1-0-B
3、在节点1的root用户下执行deletedisk删除ASM磁盘




    --删除磁盘# oracleasm deletedisk YWZD1Clearing disk header: doneDropping disk: done
# oracleasm listdisks | grep YWZD-->无记录
# oracleasm scandisksReloading disk partitions: doneCleaning any stale ASM disks...Scanning system for ASM disks...
4、在节点2检查ASM的状态，磁盘状态从MEMBER变成为CANDIDATE。
--检查磁盘状态为CANDIDATEcol path for a40col name for a20set linesize 1000select path,name,state ,header_status from v$asm_disk where path like '%YWZD%';PATH                     NAME              STATE    HEADER_STATU---------------------------------------- -------------------- -------- ------------/dev/oracleasm/disks/YWZD1                      NORMAL   CANDIDATE
--ASM磁盘扫描# oracleasm scandisksReloading disk partitions: doneCleaning any stale ASM disks...Cleaning disk "YWZD1"Scanning system for ASM disks...
# oracleasm listdisks | grep YWZD-->无记录
select path,name,state ,header_status from v$asm_disk where path like '%YWZD%'; no rows selected
5、检查数据库文件的状态，已经无法识别到数据文件。
--查看数据文件状态为AVAILABLEcol file_name for a60select file_name ,status from dba_data_files where file_name like '+YWZD%'; FILE_NAME                             STATUS------------------------------------------------------------ ---------+YWZD/ywzd/DATAFILE/ywzd.257.1164789351             AVAILABLE
--手动触发检查点alter system checkpoint;alter system checkpoint;
--物理磁盘检测异常，触发磁盘组dismountedselect file_name ,status from dba_data_files where file_name like '+YWZD%'*ERROR at line 1:ORA-01187: cannot read from file  because it failed verification testsORA-01110: data file 10: '+YWZD/ywzd/DATAFILE/ywzd.257.1164789351'
--ASM日志2024-03-28T22:21:01.941213+08:00Errors in file /u01/app/oracle/diag/rdbms/ywzd/ywzd1/trace/ywzd1_ckpt_16646.trc:ORA-01110: data file 10: '+YWZD/ywzd/DATAFILE/ywzd.257.1164789351'ORA-01115: IO error reading block from file 10 (block # 1)ORA-15078: ASM diskgroup was forcibly dismountedORA-15078: ASM diskgroup was forcibly dismounted
‍
6、asm磁盘头的元数据在0号数据块，其备份的元数据在510号数据块，因此可以通过kfed repair来修复。
-- 执行修复命令触发KFED-00303# su - grid$ kfed repair /dev/oracleasm/disks/YWZD1KFED-00303: unable to open file '/dev/oracleasm/disks/YWZD1'
 --通过命令把原先的ASM磁盘状态写入磁盘头（renamedisk -f）$oracleasm createdisk YWZD1 /dev/mapper/YW-YWZD Unable to open device "/dev/mapper/YW-YWZD": Permission denied
--root用户下创建# oracleasm createdisk YWZD1 /dev/mapper/YW-YWZDWriting disk header: doneInstantiating disk: done
--检查ASM磁盘状态为PROVISIONED PATH                     NAME              STATE    HEADER_STATU---------------------------------------- -------------------- -------- ------------/dev/oracleasm/disks/YWZD1                      NORMAL   PROVISIONED
--再次执行kfed repair进行修复，并通过strace把日志记录下来。strace -o asm_learn.log kfed repair /dev/oracleasm/disks/YWZD1
--再次检查磁盘状态，已变成MEMBERPATH                     NAME              STATE    HEADER_STATU---------------------------------------- -------------------- -------- ------------/dev/oracleasm/disks/YWZD1                      NORMAL   MEMBER
--另一个节点扫描磁盘# oracleasm scandisksReloading disk partitions: doneCleaning any stale ASM disks...Scanning system for ASM disks...Instantiating disk "YWZD1"
--手动挂载两个节点的磁盘组SQL> select name,state from v$asm_diskgroup; NAME                   STATE------------------------------ -----------YWZD                   DISMOUNTED
SQL> alter diskgroup ywzd mount;Diskgroup altered.
7、检查数据文件状态及验证数据。
--数据文件读取异常select file_name ,status from dba_data_files where file_name like '+YWZD%'*ERROR at line 1:ORA-01187: cannot read from file  because it failed verification testsORA-01110: data file 10: '+YWZD/ywzd/DATAFILE/ywzd.257.1164789351'
--错误码信息!oerr ora 0118701187, 00000, "cannot read from file %s because it failed verification tests"// *Cause:  The data file did not pass the checks to insure it is part of the//         database. Reads are not allowed until it is verified.// *Action: Make the correct file available to the database. Then, either open//         the database, or execute ALTER SYSTEM CHECK DATAFILES.
--手动进行数据文件校验 alter database datafile 10 online;Database altered.
ALTER SYSTEM CHECK DATAFILES; Database altered.
--数据文件状态恢复正常select file_name ,status from dba_data_files where file_name like '+YWZD%';FILE_NAME                             STATUS------------------------------------------------------------ ---------+YWZD/ywzd/DATAFILE/ywzd.257.1164789351             AVAILABLE
--数据成功恢复SYS@ywzd1> select count(*) from ywzd;
  COUNT(*)----------      1884
‍根据以上步骤成功将ASM磁盘、ASM磁盘组和数据文件成功恢复出来。
虽然整个恢复过程步骤简单，但是还是要理解其中的原理。数据库底层未实际删除数据，而修改ASM磁盘头状态信息。可使用kfed工具手动调整磁盘头状态或将元数据备份直接恢复。
1、ASM磁盘头HEADER_STATUS的状态，常见有以下4种。
CANDIDATE\PROVISIONED：磁盘不是磁盘组的一部分，可以通过以下ALTER DISKGROUP语句添加到磁盘组中MEMBER：磁盘是现有磁盘组的成员。请勿尝试将磁盘添加到其他磁盘组FORMER：磁盘曾经是磁盘组的一部分，但已从该组中彻底删除。可以使用以下ALTER DISKGROUP语句将其添加到新的磁盘组中
‍2、正常情况下，可通过kfed read检查以下关键指标




    kfbh.type 值为 KFBTYP_DISKHEADkfdhdb.hdrsts 值为 KFDHDR_MEMBER
  • ASM tools used by Support : KFOD, KFED, AMDU (Doc ID 1485597.1)
  • https://blog.csdn.net/allway2/article/details/107250526/
以上就是本期关于“使用kfed运维兵器修复ASM磁盘和磁盘组”。希望能给大家带来帮助！
