【问题诊断】Oracle 11g ORA-7445 [opiaba] 和 ORA-600 [17147]错误案例分享

集群环境：srvctl status database -d ywzd2 -vInstance ywzd21 is running on node ywzd-db03. Instance status: Open.Instance ywzd22 is running on node ywzd-db04. Instance status: Open.
单机环境：sqlplus / as sysdbaSQL> select startup_time,status from v$instance;STARTUP_TIME        STATUS----------------------- ------------06-DEC-2023 12:29:59    OPEN

第一段日志出现ORA-07445[opiaba()+639]错误Wed Dec 06 12:29:21 2023Exception [type: SIGSEGV, SI_KERNEL(general_protection)] [ADDR:0x0] [PC:0x185806F, opiaba()+639] [flags: 0x0, count: 1]Errors in file /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/trace/ywzd21_ora_538783.trc  (incident=418676):ORA-07445: exception encountered: core dump [opiaba()+639] [SIGSEGV] [ADDR:0x0] [PC:0x185806F] [SI_KERNEL(general_protection)] []Incident details in: /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/incident/incdir_418676/ywzd21_ora_538783_i418676.trc第二段日志出现ORA-00600[17147]错误Wed Dec 06 12:29:47 2023Errors in file /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/trace/ywzd21_pmon_512337.trc  (incident=411292):ORA-00600: internal error code, arguments: [17147], [0x14DAE09578], [], [], [], [], [], [], [], [], [], []Incident details in: /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/incident/incdir_411292/ywzd21_pmon_512337_i411292.trcUse ADRCI or Support Workbench to package the incident.See Note 411.1 at My Oracle Support for error and packaging details.Wed Dec 06 12:29:48 2023Dumping diagnostic data in directory=[cdmp_20231206122948], requested by (instance=1, osid=512337 (PMON)), summary=[incident=411292].Errors in file /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/trace/ywzd21_pmon_512337.trc:ORA-00600: internal error code, arguments: [17147], [0x14DAE09578], [], [], [], [], [], [], [], [], [], []PMON (ospid: 512337): terminating the instance due to error 472System state dump requested by (instance=1, osid=512337 (PMON)), summary=[abnormal instance termination].System State dumped to trace file /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/trace/ywzd21_diag_512357_20231206122952.trcInstance terminated by PMON, pid = 512337第三段日志集群实例自动重启Wed Dec 06 12:29:59 2023Starting ORACLE instance (normal)
批量检查命令：grep -ib1E 'opiaba|\[17147|terminating the instance due to error 472' /u01/app/oracle/diag/rdbms/ywzd2/ywzd21/trace/alert_ywzd21.log

========= Dump for incident 328879 (ORA 600 [17147]) ========----- Beginning of Customized Incident Dump(s) -----********** Internal heap ERROR 17147 addr=0x12b0accc78 *********...
dbkedDefDump(): Starting incident default dumps (flags=0x2, level=3, mask=0x0)----- Current SQL Statement for this session (sql_id=btng01wnhnvnw) -----begin
update 业务表1set 字段1 = :1 ,字段2 = :2 ,字段3 = :3 ,字段4 = :4 ,字段5 = :5 ,字段6 = :6 ,字段7 = '1'where 字段8 = :7and 字段9 = :8and 字段10 = :9 ;
....（sql 太长，部分省略）...
update 业务表Nset 字段1 = :100381 ,字段2 = :100382 ,字段3 = :100383where 字段4 = :100384and 字段5 = :100385and 字段6 = :100386 ;end;

dbkedDefDump(): Starting incident default dumps (flags=0x2, level=3, mask=0x0)----- SQL Statement (None) -----Current SQL information unavailable - no cursor....
----- Incident Context Dump -----Address: 0x7fff22dbad78Incident ID: 327263Problem Key: ORA 600 [17147]Error: ORA-600 [17147] [0x12B0ACCC78] [] [] [] [] [] [] [] [] [] [][00]: dbgexExplicitEndInc [diag_dde][01]: dbgeEndDDEInvocationImpl [diag_dde][02]: dbgeEndDDEInvocation [diag_dde][03]: kgherror [KGH]<-- Signaling[04]: kghfrmrg [KGH][05]: kghfre [KGH][06]: kghsfx [KGH][07]: kghunfhp [KGH][08]: kghfrh_internal [KGH][09]: kghfrh [KGH][10]: kksFreeHeap [cursor][11]: kksLockDelete [cursor][12]: kksLockOperation [cursor][13]: kgllkdl [LIBCACHE][14]: kgllkds [LIBCACHE][15]: kssxdl [VOS][16]: kssdel [VOS][17]: kssdch [VOS][18]: ksuxds [ksu][19]: kssxdl [VOS][20]: kssdel [VOS][21]: kssdch [VOS][22]: ksudlp [ksu][23]: kssxdl [VOS][24]: kssdel [VOS][25]: ksuxdl [ksu][26]: ksuxda_del_proc [ksu][27]: ksucln_dpc_cleanup [ksu][28]: ksucln_dpc_dfs [ksu][29]: ksucln_dpc_main [ksu][30]: ksucln_dpc [ksu][31]: ksucln [ksu][32]: ksbrdp [background_proc][33]: opirip []

select sql_id, count(*) bind_count  from v$sql_bind_capture t where t.CHILD_NUMBER = 0 group by t.SQL_IDhaving count(*) > 1000 order by count(*);

-------------堆栈调用函数-------------------kgdsdst   skdstdst                operating system dependent kernel dump a stack traceksedst1                 kernel service (VOS) error debug dump the call stack stack trace 1 helperksedst                  kernel service (VOS) error debug dump the call stackdbkedDefDump            debug and diagnostics RDBMS diagnostic data extractor Dumper do DDE default dumpksedmp                  kernel service (VOS) error debug dump process statessexhd                  operating system dependent system dump routine__sighandler        opiabaopiprs                  oracle program interface parsekksParseChildCursor     kernel compile shared objects (cursor) parse child cursorrpiswu2                 recursive program interface switch user in recursive sqlkksLoadChild            kernel compile shared objects (cursor) load childkxsGetRuntimeLock       kernel execution shared cursor get runtime lockkksfbc                  kernel compile shared objects (cursor) find bound cursorkkspsc0                 kernel compile shared objects (cursor) parse shared cursorkksParseCursor          kernel compile shared objects (cursor) parse cursoropiosq0                 oracle program interface prepare to parse a sql command 0kpooprx                 kernel programmatic interface oracle open, parse, and optionally executekpoal8                  kernel programmatic interface oracle V8 bundled executionopiodr                  oracle program interface oracle code request driver, route the current requestttcpip                  two task common pipe read/writeopitsk                  oracle program interface two task function dispatcheropiino                  oracle program interface initialize opiopiodr opidrv                  oracle program interface route current request driver, entry side into two task interfacesou2o                   main oracle executable entry pointopimai_real             oracle program interface main real oracle start pointssthrdmain              operating system dependent system main for every thread in a threaded oraclemain                    general c starting function

1、创建测试表create table test01 as select * from dba_tables;2、修改共享游标参数值为SIMILARalter session set CURSOR_SHARING=SIMILAR; 3、第一次执行语句1select table_name from test01 where table_name='OBJ$';4、查看语句1的SQL_ID和执行次数set linesize 1000col sql_text for a80select sql_id,EXECUTIONS,LOADS,sql_text from v$sql where sql_text like 'select table_name from test01 where table_name%';SQL_ID          EXECUTIONS      LOADS SQL_TEXT------------- ---------- ---------- ----------------------------------------------------------------------------------------------------9dhppyxtr9qck           1      1 select table_name from test01 where table_name=:"SYS_B_0"5、通过SQL_ID获取语句1的绑定变量值col value_string for a30select child_address,to_char(LAST_CAPTURED,'dd-mm-yyyy hh24:mi:ss'),VALUE_STRING from v$sql_bind_capture where sql_id='9dhppyxtr9qck';CHILD_ADDRESS     TO_CHAR(LAST_CAPTUR VALUE_STRING---------------- ------------------- ------------------------------0000000068BD8220 17-03-2024 20:32:52 OBJ$6、查看参数_cursor_bind_capture_interval的值为900秒，默认15分钟set linesize 1000col name for a50col value for a30select nam.ksppinm NAME,val.KSPPSTVL VALUE from x$ksppi nam, x$ksppsv val where nam.indx = val.indx and nam.ksppinm like '%_cursor_bind_capture_interval%' order by 1;7、修改动态参数为10秒捕获一次alter system set "_cursor_bind_capture_interval"=10;8、再次执行语句1，参数值不一样，传入参数须为4个字节，避免硬解析select table_name from test01 where table_name='TAB$';9、再次查询绑定变值，已从COL$变为TAB$CHILD_ADDRESS     TO_CHAR(LAST_CAPTUR VALUE_STRING---------------- ------------------- ------------------------------0000000068BD8220 17-03-2024 20:35:56 TAB$
