Spring Cloud Gateway路由处理流程

public class DispatcherHandler implements WebHandler {  public Mono<Void> handle(ServerWebExchange exchange) {    // ...    return Flux.fromIterable(this.handlerMappings)        // 找到合适的HandlerMapping        // concatMap同步执行        .concatMap(mapping -> mapping.getHandler(exchange))        // 获取第一个元素        .next()        // 如果没有则创建一个错误        .switchIfEmpty(createNotFoundError())        // 找到合适的处理器HandlerAdapter        // 异步执行        .flatMap(handler -> invokeHandler(exchange, handler))        // 找到合适的HandlerResult        .flatMap(result -> handleResult(exchange, result));  }}

// 获取所有的全局过滤器@Beanpublic FilteringWebHandler filteringWebHandler(List<GlobalFilter> globalFilters) {  return new FilteringWebHandler(globalFilters);}

public class SimpleHandlerAdapter implements HandlerAdapter {
  @Override  public boolean supports(Object handler) {    return WebHandler.class.isAssignableFrom(handler.getClass());  }
  @Override  public Mono<HandlerResult> handle(ServerWebExchange exchange, Object handler) {    WebHandler webHandler = (WebHandler) handler;    // 通过上面知道了这里的handler = FilteringWebHandler对象    Mono<Void> mono = webHandler.handle(exchange);    return mono.then(Mono.empty());  }
}

public class FilteringWebHandler implements WebHandler {
  protected static final Log logger = LogFactory.getLog(FilteringWebHandler.class);
  private final List<GatewayFilter> globalFilters;
  public FilteringWebHandler(List<GlobalFilter> globalFilters) {    // 将全局过滤器转换为GatewayFilter，通过GatewayFilterAdapter进行适配    this.globalFilters = loadFilters(globalFilters);  }
  private static List<GatewayFilter> loadFilters(List<GlobalFilter> filters) {    return filters.stream().map(filter -> {      GatewayFilterAdapter gatewayFilter = new GatewayFilterAdapter(filter);      if (filter instanceof Ordered) {        int order = ((Ordered) filter).getOrder();        return new OrderedGatewayFilter(gatewayFilter, order);      }      return gatewayFilter;    }).collect(Collectors.toList());  }  private static class GatewayFilterAdapter implements GatewayFilter {
    private final GlobalFilter delegate;
    GatewayFilterAdapter(GlobalFilter delegate) {      this.delegate = delegate;    }
    @Override    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {      return this.delegate.filter(exchange, chain);    }
    @Override    public String toString() {      final StringBuilder sb = new StringBuilder("GatewayFilterAdapter{");      sb.append("delegate=").append(delegate);      sb.append('}');      return sb.toString();    }
  }}

public class FilteringWebHandler implements WebHandler {  public Mono<Void> handle(ServerWebExchange exchange) {    // 取得在上面第2步中路由（从上下文ServerwebExchange）    Route route = exchange.getRequiredAttribute(GATEWAY_ROUTE_ATTR);    // 获取路由中配置的过滤器    List<GatewayFilter> gatewayFilters = route.getFilters();    // 将路由中配置的过滤器与全局过滤器（自定义的GlobalFilter和系统的过滤器）    List<GatewayFilter> combined = new ArrayList<>(this.globalFilters);    combined.addAll(gatewayFilters);    // 排序    AnnotationAwareOrderComparator.sort(combined);    // 构建过滤器执行链执行过滤器    return new DefaultGatewayFilterChain(combined).filter(exchange);  }}

spring:  cloud:    gateway:      enabled: true      # 全局超时配置      httpclient:        connect-timeout: 10000        response-timeout: 5000      discovery:        locator:          enabled: true          lowerCaseServiceId: true      # 这里是全局过滤器，也就是下面在介绍过滤器执行的时候一定会执行StripPrefixGatewayFilterFactory#apply      # 返回的过滤器，如下路由配置：该过滤器会将你的请求转换为：http://localhost:8088/demos，保存到上下文中      # ServerWebExchange#getAttributes().put(GATEWAY_REQUEST_URL_ATTR, newRequest.getURI())      default-filters:      - StripPrefix=1      routes:      - id: R001        uri: http://localhost:8787        predicates:        - Path=/api-1/**,/api-2/**        metadata:          akf: "dbc"          #局部超时设置          connect-timeout: 10000          response-timeout: 5000

ServerWebExchange#getAttributes().put(GATEWAY_REQUEST_URL_ATTR, mergedUrl);

public class NettyRoutingFilter implements GlobalFilter {  private final HttpClient httpClient;  public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {    // 从上下文中获取解析后的目标地址    URI requestUrl = exchange.getRequiredAttribute(GATEWAY_REQUEST_URL_ATTR);    // ...    // 获取上下文中的路由信息    Route route = exchange.getAttribute(GATEWAY_ROUTE_ATTR);    // getHttpClient获取客户端信息    Flux<HttpClientResponse> responseFlux = getHttpClient(route, exchange).headers(headers -> {      // ...    }).request(method).uri(url).send((req, nettyOutbound) -> {      // 发送网络请求      return nettyOutbound.send(request.getBody().map(this::getByteBuf));    }).responseConnection((res, connection) -> {      exchange.getAttributes().put(CLIENT_RESPONSE_ATTR, res);      exchange.getAttributes().put(CLIENT_RESPONSE_CONN_ATTR, connection);
      ServerHttpResponse response = exchange.getResponse();      HttpHeaders headers = new HttpHeaders();
      res.responseHeaders().forEach(entry -> headers.add(entry.getKey(), entry.getValue()));
      String contentTypeValue = headers.getFirst(HttpHeaders.CONTENT_TYPE);      if (StringUtils.hasLength(contentTypeValue)) {        exchange.getAttributes().put(ORIGINAL_RESPONSE_CONTENT_TYPE_ATTR, contentTypeValue);      }      setResponseStatus(res, response);      HttpHeaders filteredResponseHeaders = HttpHeadersFilter.filter(getHeadersFilters(), headers, exchange,          Type.RESPONSE);
      if (!filteredResponseHeaders.containsKey(HttpHeaders.TRANSFER_ENCODING)          && filteredResponseHeaders.containsKey(HttpHeaders.CONTENT_LENGTH)) {        response.getHeaders().remove(HttpHeaders.TRANSFER_ENCODING);      }
      exchange.getAttributes().put(CLIENT_RESPONSE_HEADER_NAMES, filteredResponseHeaders.keySet());
      response.getHeaders().putAll(filteredResponseHeaders);
      return Mono.just(res);    });
    // 从路由中的元数据中获取response-timeout响应超时时间    Duration responseTimeout = getResponseTimeout(route);    if (responseTimeout != null) {      responseFlux = responseFlux          // 设置超时时间          .timeout(responseTimeout,              Mono.error(new TimeoutException("Response took longer than timeout: " + responseTimeout)))          .onErrorMap(TimeoutException.class,              th -> new ResponseStatusException(HttpStatus.GATEWAY_TIMEOUT, th.getMessage(), th));    }    return responseFlux.then(chain.filter(exchange));  }  protected HttpClient getHttpClient(Route route, ServerWebExchange exchange) {    // 从路由的元数据中获取配置的连接超时时间：connect-timeout    Object connectTimeoutAttr = route.getMetadata().get(CONNECT_TIMEOUT_ATTR);    if (connectTimeoutAttr != null) {      Integer connectTimeout = getInteger(connectTimeoutAttr);      // 设置Netty的连接超时时间      // io.netty.channel.ChannelOption      return this.httpClient.option(ChannelOption.CONNECT_TIMEOUT_MILLIS, connectTimeout);    }    return httpClient;  }}
