PG基于备份和WAL日志恢复数据

db5=# select name,setting from pg_settings where name in ('wal_level','archive_mode','archive_command','restore_command');      name       |         setting-----------------+------------------------- archive_command | cp %p /opt/pgwal/arc/%f archive_mode    | on restore_command | cp /opt/pgwal/arc/%f %p wal_level       | replica(4 rows)

[postgres@pg2 opt]$ pg_basebackup -Fp -Xs -P -v -D /opt/pgdata -h luoPassword:pg_basebackup: initiating base backup, waiting for checkpoint to completepg_basebackup: checkpoint completedpg_basebackup: write-ahead log start point: 0/2C000028 on timeline 1pg_basebackup: starting background WAL receiverpg_basebackup: created temporary replication slot "pg_basebackup_13727"55973/55973 kB (100%), 1/1 tablespacepg_basebackup: write-ahead log end point: 0/2C000158pg_basebackup: waiting for background process to finish streaming ...pg_basebackup: syncing data to disk ...pg_basebackup: renaming backup_manifest.tmp to backup_manifestpg_basebackup: base backup completed

postgres=# create database db5;        --新建一个数据库db5CREATE DATABASEpostgres=#postgres=#postgres=#postgres=# \c db5You are now connected to database "db5" as user "postgres".db5=# create table t1 as select * from pg_class;SELECT 415db5=#db5=#db5=# create table t2 (id int);       CREATE TABLEdb5=# insert into t2 values(1);INSERT 0 1db5=# insert into t2 values(2);INSERT 0 1db5=#db5=#db5=#db5=# select * from t2; id----  1  2(2 rows)db5=# delete from t2 where id=2;          --模拟误操作，删除t2表上一行数据DELETE 1db5=# select * from t2; id----  1(1 row)db5=# create table t3(id int);            --新建t3表CREATE TABLEdb5=# checkpoint ;CHECKPOINTdb5=# select pg_switch_wal();               --切换WAL日志 pg_switch_wal--------------- 0/2D46A8A0(1 row)db5=#db5=# select pg_relation_filepath('t2');      --查看t2表文件名，文件名是16485 pg_relation_filepath                               ---------------------- base/16479/16485(1 row)db5=# \d        List of relations Schema | Name | Type  |  Owner--------+------+-------+---------- public | t1   | table | postgres public | t2   | table | postgres public | t3   | table | postgres(3 rows)db5=# select * from t2; id----  1(1 row)

[postgres@luo arc]$[postgres@luo arc]$ pwd                  --归档目录/opt/pgwal/arc[postgres@luo arc]$ ls -lrt              --根据时间列出WAL日志总用量 65540-rw------- 1 postgres dba 16777216 8月  27 16:08 00000001000000000000002A-rw------- 1 postgres dba 16777216 8月  27 16:10 00000001000000000000002B-rw------- 1 postgres dba 16777216 8月  27 16:10 00000001000000000000002C-rw------- 1 postgres dba      341 8月  27 16:10 00000001000000000000002C.00000028.backup-rw------- 1 postgres dba 16777216 8月  27 16:13 00000001000000000000002D[postgres@luo arc]$

[postgres@luo arc]$ pg_waldump 00000001000000000000002D|grep -i delete|grep 16485rmgr: Heap        len (rec/tot):     54/    54, tx:        833, lsn: 0/2D469640, prev 0/2D469608, desc: DELETE xmax: 833, off: 2, infobits: [KEYS_UPDATED], flags: 0x00, blkref #0: rel 1663/16479/16485 blk 0[postgres@luo arc]$

vi postgresql.confrecovery_target_lsn = '0/2D469608'            --lsn为上一个lsn

[postgres@pg2 pgdata]$ cd /opt/pgdata/[postgres@pg2 pgdata]$ touch standby.signal[postgres@pg2 pgdata]$[postgres@pg2 pgdata]$ ll总用量 388-rw------- 1 postgres dba    227 8月  27 16:10 backup_label.old-rw------- 1 postgres dba 318484 8月  27 16:10 backup_manifestdrwx------ 6 postgres dba     46 8月  27 16:18 base-rw------- 1 postgres dba     47 8月  27 16:17 current_logfilesdrwx------ 2 postgres dba   4096 8月  27 16:18 globaldrwx------ 2 postgres dba      6 8月  27 16:10 pg_commit_tsdrwx------ 2 postgres dba      6 8月  27 16:10 pg_dynshmem-rw------- 1 postgres dba   5867 8月  27 16:10 pg_hba.conf-rw------- 1 postgres dba   2640 8月  27 16:10 pg_ident.confdrwx------ 2 postgres dba   4096 8月  27 16:17 pg_logdrwx------ 4 postgres dba     68 8月  27 16:22 pg_logicaldrwx------ 4 postgres dba     36 8月  27 16:10 pg_multixactdrwx------ 2 postgres dba      6 8月  27 16:10 pg_notifydrwx------ 2 postgres dba      6 8月  27 16:10 pg_replslotdrwx------ 2 postgres dba      6 8月  27 16:10 pg_serialdrwx------ 2 postgres dba      6 8月  27 16:10 pg_snapshotsdrwx------ 2 postgres dba      6 8月  27 16:10 pg_statdrwx------ 2 postgres dba      6 8月  27 16:10 pg_stat_tmpdrwx------ 2 postgres dba     18 8月  27 16:22 pg_subtransdrwx------ 2 postgres dba      6 8月  27 16:10 pg_tblspcdrwx------ 2 postgres dba      6 8月  27 16:10 pg_twophase-rw------- 1 postgres dba      3 8月  27 16:10 PG_VERSIONdrwx------ 4 postgres dba     77 8月  27 16:24 pg_waldrwx------ 2 postgres dba     18 8月  27 16:10 pg_xact-rw------- 1 postgres dba     88 8月  27 16:10 postgresql.auto.conf-rw------- 1 postgres dba  30969 8月  27 16:17 postgresql.conf-rw------- 1 postgres dba     23 8月  27 16:17 postmaster.opts-rw------- 1 postgres dba     70 8月  27 16:17 postmaster.pid-rw-r--r-- 1 postgres dba      0 8月  27 16:11 standby.signal[postgres@pg2 pgdata]$

[postgres@pg2 pgdata]$ pg_ctl startwaiting for server to start....2025-08-27 16:17:42.609 CST [14902] :[ [txid=0] user= ,db=,app=,client=LOG:  redirecting log output to logging collector process2025-08-27 16:17:42.609 CST [14902] :[ [txid=0] user= ,db=,app=,client=HINT:  Future log output will appear in directory "pg_log". doneserver started

2025-08-27 17:17:40.417 CST [15577] :[ [txid=0] user= ,db=,app=,client=LOG:  database system is ready to accept read-only connectionscp: 无法获取"/opt/pgwal/arc/00000001000000000000002D" 的文件状态(stat): 没有那个文件或目录

[postgres@luo arc]$ scp 00000001000000000000002D pg2:/opt/pgwal/arcpostgres@pg2's password:00000001000000000000002D                                                                                         100%   16MB  13.9MB/s   00:01[postgres@luo arc]$

cp: 无法获取"/opt/pgwal/arc/00000002.history" 的文件状态(stat): 没有那个文件或目录2025-08-27 17:20:00.706 CST [15581] :[ [txid=0] user= ,db=,app=,client=LOG:  waiting for WAL to become available at 0/2D0000182025-08-27 17:20:05.694 CST [15581] :[ [txid=0] user= ,db=,app=,client=LOG:  restored log file "00000001000000000000002D" from archivecp: 无法获取"/opt/pgwal/arc/00000001000000000000002E" 的文件状态(stat): 没有那个文件或目录2025-08-27 17:20:05.740 CST [15581] :[ [txid=0] user= ,db=,app=,client=LOG:  recovery stopping after WAL location (LSN) "0/2D469608"2025-08-27 17:20:05.741 CST [15581] :[ [txid=0] user= ,db=,app=,client=LOG:  pausing at the end of recovery2025-08-27 17:20:05.741 CST [15581] :[ [txid=0] user= ,db=,app=,client=HINT:  Execute pg_wal_replay_resume() to promote.

[postgres@luo ~]$ psql db5psql (17.0)Type "help" for help.db5=# \d        List of relations Schema | Name | Type  |  Owner--------+------+-------+---------- public | t1   | table | postgres public | t2   | table | postgres public | t3   | table | postgres(3 rows)db5=# select * from t2; id----  1(1 row)db5=#

[postgres@pg2 pgdata]$ psql db5psql (17.0)Type "help" for help.db5=# \d        List of relations Schema | Name | Type  |  Owner--------+------+-------+---------- public | t1   | table | postgres public | t2   | table | postgres(2 rows)db5=# select * from t2; id----  1  2(2 rows)db5=#
