ZTF Global WiFi TT

ZTF Global WiFi TT GSTAR中友出海圈
2025-10-22
14

The Global WiFi TT, developed by NRadio, is a portable 4G MiFi device that supports universal frequency bands, covering over 200 operator networks in more than 140 countries and regions worldwide. It's a single-frequency 4G MiFi that comes equipped with a 10,000mAh battery. The 4G module utilizes the TM22G-LGA module, while the WiFi chip utilizes the SV6158-M. The device features 1 Type-C port that supports both input and output, 1 Lightning port for input, as well as two built-in line outputs for Type-C and Lightning. Additionally, it includes an external card slot.

Features

nGlobal frequency band, ultra-wide coverage

supports Cloud-SIM technology and supports the full global 4G bands and intelligently and automatically selects the registered network based on network signal coverage for optimal coverage and performance.

nFreedom and convenient

It adopts wireless network access to get rid of the constraints of network cables, telephone lines, and fiber, allowing more freedom in placement and faster temporary construction.

nSimple shape, compact and lightweight

Pure white color, rectangular arc shape, easy to carry, simple appearance, put it in the bag and have network and electricity everywhere.

nMultiple applicable scenarios and wide range of product applications

It is suitable for various wireless broadband scenarios such as individuals/small and medium-sized enterprises/shops/homes/monitoring/temporary network use, and the traffic rates are more economical.

nComes with built-in battery, long battery life

It comes with a 10000mAh battery with a battery life of up to 48 hours. It comes with a digital display screen and a Type-C interface and Lightning interface input to charge the battery, which is convenient and fast.

nComes with dual wires and fast charging technology

Comes with Type-C and Lightning fast charging cables to charge external devices.

Specification

Hardware parameters

Interface & Ports

One (1) Nano SIM

One (1) Type-C power interface

One (1) Lightning power interface

Power display

One (1) Nixie Tube

Button

One(1) Reset

One(1) Power Button

LED

One(1) green/orange Network LED

Battery

10000mAh

Antenna

One(1) PCB 2.4G antenna

Two(2) 4G LTE antenna

Operating temperature

0~40°C10%90%

Storage humidity

-40~70°C5%95%

physical dimension

160*75*20 mm

Weight specifications

259g

Lightning protection level

2KV

Standby power consumption

1W

Maximum power consumption

4W

OUT

Type-C OUT4.5V/5A 5V/4.5A 5V/3A 9V/2.22A 12V/1.67A 22.5W
Lighting OUT5V/3A9V/2.22A12V/1.67A 20W

All OUT5V/3A(Type-Clightning Cable)

hardware information

technical standard

TDD/FDD LTE CAT4

20MHz RF bandwidth

LTE FDD: 150Mbps (DL) / 50Mbps (UL)

LTE TDD: 130Mbps (DL)/ 30Mbps (UL)

Band

LTE-FDD
B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B17/B18/B19/B20/B25/B
26/B28AB/B66
TDD-LTEB34/B38/B39/B40/B41
WCDMAB1
GSM/GPRS/EDGE: B1/B2/B4/B5/B8

Maximum number

8

软件功能

APN

Support

SIM mode

Support

Maximum number

Support

Revise SSID

Support

Encryption

WPA2
