巴基斯坦采购转子流量计
基本信息
项目名称：采购转子流量计
采购国家：巴基斯坦
采购数量：4种
截止日期：2018年09月14日
物品规格
Item 1.GLASS TUBE ROTAMETER
Range: 150 -1500 Ltr/Hr
Fluid: Ether
Min. Resolution: 50 Ltr /Hr
Specific Gravity: 0.72 kg/Ltr
Fluid Temperature: 60 °C
Face to Face Length: 460 mm approx (Inlet to Outlet)
Minimum Glass Tube Length: 200-300
Rota meter Frame Material: Suitable for above fluid
Flange Dia: 110 mm approx (Properly marked as shown on Picture # 5)
No. of Holes in Flange: 04 No
Line size: 10 mm
Float Material: Suitable for above fluid (Preferably PTFE if suitable)
Process Connection: Flanged Right Angle (as shown in Picture # 6 & Pic. 7)
Spare parts:
Spare Glass Tube: 02 No.
Spare Float : 01 No.
Item 2. GLASS TUBE ROTAMETER
Range: 0-110 Gal/Hr (Approximately)
Fluid: Sulphuric Acid (Concentrated)
Min. Resolution: 10 Gal/Hr
Specific Gravity: 1.840
Fluid Temperature: 25 °C
Face to Face Length: 350 mm approx (Inlet to Outlet)
Minimum Glass Tube Length: 200-300
Rotameter Frame Material: Suitable for above fluid
Flange Dia: 125mm approx (Properly marked as shown on Picture # 5)
No. of Holes in Flange: 04 Nos
Line size: 25 mm
Float Material: PTFE
Process Connection & Configuration: (As shown in Picture # 7)
Spare parts:
Spare Glass Tube : 02 No.
Spare Float : 01 No.
Item 3.: GLASS TUBE ROTAMETER
Range: 0-600 Ltr /Hr
Fluid: Ether
Min. Resolution: 60 Ltr/Hr approx
Specific Gravity: 0.72 Kg/Ltr
Fluid Temperature: 60 °C
Face to Face Length: 580 mm approx (Inlet to Outlet)
Minimum Glass Tube Length: 200-300
Rotameter Frame Material: Suitable for above fluid
Flange Dia: 110 mm approx
No. of Hole in Flange: 04 NOs
Line size: 25 mm Float Material: Suitable for above fluid
Process Connection & Configuration: Flanged Right Angle (as shown in Picture # 5 & Pic 7)
Spare Parts:
Spare Glass Tube: 02 Nos.
Spare Float: 01 No
Item 4. GLASS TUBE ROTAMETER WITH HOUSING DN 50
Range 400-5500 KG / HR Approximately preferably in Kgs
Fluid :Nitric Acid 30 % + Sulphuric Acid 60 -62 %+ Water 7-9%
Min. Resolution: 100 Kg/Hr
Specific Gravity: 1.73 Kg/Ltr
Viscosity: 40 mPas
Fluid Temperature: 0 °C
Face to Face Length: 800 mm (Inlet to Outlet)
Minimum Glass Tube Length: 450-500 mm
Rotameter Frame Material: Suitable for above fluid
Flange Dia: 170 mm( Properly marked as shown on Picture # 7)
No. of Hole in Flange: 04Nos
Line size: 50 mm
Float Material: PTFE
Spare Parts:
Spare Glass Tube: 02 Nos. Spare Float: 01 No
资质要求
1.厂家营业执照
2.产品报价单
3.相关产品英文图册
