FEATURES:
1. Very low dissipation factor,
suitable for high frequency application.
2. Negative temperature coefficient.
3. High reliability and high insulation resistance.
4. High reliability and high insulation resistance.
5. Very high dv/dt value.
APPLICATION:
High frequency tuning, yoke coupling, voltage retrace in T.V. and monitor circuit,electronic ballasts.
GENERAL SPECIFICATION:
1.Capacitance range: 0.01~2.0 µF
2. Voltage range:
600/630,1000,1200,1600,2000VDC
3. Operating temperature: -40℃ ~ +105℃
4. Dissipation factor: ≦0.1%(AT 1.0 KHz)
