随着IEC60598-1:2014+A1:2017在2017年9月15日发布并实施，针对移动式夹子灯的钳夹装置的评估测试要求发生变更，产品将相对更容易通过测试。
| 旧要求（IEC60598-1:2014） | 新要求（IEC60598-1:2014+A1:2017） | |||
| Test E: For clip-mounted luminaires: A pull is applied to the cable without jerk for 1 min in the most unfavourable direction in normal use. During the test, the clip is mounted on standard test "shelves" made of ordinary window glass, one with a nominal thickness of 10 mm and one with the maximum thickness onto which the clip can be mounted. For this test, the thickness of the test shelf is increased by multiples of 10 mm. The clip shall not start moving on the glass at a pull of 20 N. | Test E: For clip-mounted luminaires: A pull is applied to the cable without jerk for 1 min in the most unfavourable direction in normal use. During the test, the clip is mounted on standard test “shelves” made of ordinary window glass, one with a nominal thickness of 10 mm and one with the maximum thickness onto which the clip can be mounted. For this test, the thickness of the test shelf is increased by multiples of 10 mm. The clip shall not fall off the glass at a pull of 20 N. | |||
| CTL决议补充： Question: Test for clip- mounted luminaires, pulling in some directions, (direction Z, see the figure). It is practically impossible to have a clip which does not start to move on glass, even though the movement could not degrade the quality of the fixing. Is there any movement permitted?
Decision: Standard has to be followed. The most unfavourable direction must be tried and no movement is allowed. |
None | |||
新标准接受样品在测试过程中轻微移动，只要钳夹装置不从测试玻璃上拉脱即视为符合标准要求。
