气动元件-气源处理 K系列 M
起订量：1个
保修期：1年
德国原装进口
欢迎咨询和下单
案例：
Central filter lubricator unit | BG5
technical data
· description : differential pressure regulated central-lubricator
· supply pressure P1 max. : 10 bar
· temperature range : 0 - 60°C
· mounting : vertical, drain down
· fixing : install in pipe line, mounting bracket
· operating differential pressure area : 0,3 - 1 bar
· recommendated operating differential pressure area : 0,5 bar
· bowl volume : 2 l
· flow range : 80 - 7000 l/min
· recommendated oil viscosity : 32 c St / 40°C
· kind of oil : CL 32 DIN 51517 - ISO VG 32
· grade of filtration of prefilter : 40 μm (absolutely)
· oil miost particle size : 0,3 - 2 μm
