technical data
l description: sinter filter centrifugal principle, diaphragm-type
pressure with relieving feature, micro mist lubricator
l medium: compressed air, neutral gases
l supply pressure P1 min.: 1,5 bar
l supply pressure P1 max.: 12 bar
l temperature range: 0 - 50°C
l bowl: PC
l drain: HA
l mounting: vertical
l filter element: 5 μm
l bowl volume lubricator: 35 cm³
l oil metering qv=1.000l/min: 10 - 20 drops/min
l oil type: CL 32 DIN 51517 - ISO VG 32
technical data
l description: sinter filter centrifugal principle, diaphragm-type
pressure with relieving feature, micro mist lubricator
l medium: compressed air, neutral gases
l supply pressure P1 min.: 1,5 bar
l supply pressure P1 max.: 12 bar
l temperature range: 0 - 50°C
l bowl: PC
l drain: HA
l mounting: vertical
l filter element: 5 μm
l bowl volume lubricator: 35 cm³
l oil metering qv=1.000l/min: 10 - 20 drops/min
l oil type: CL 32 DIN 51517 - ISO VG 32
