导读：Issue 32：Dyeing and Finishing Step 19: Finished Product Fixed-Length Measurement

Xiangyun Sha, originally known as "Liang Sha", specifically referred to a silk gauze (a lightweight, open-work fabric woven with the leno jacquard technique, commonly called "twisted-eye openwork") patterned with designs such as swastika motifs, victory flowers, walnut patterns, or checkboards. The gauze was then processed through sun-dyeing (a unique dyeing and finishing technique for Xiangyun Sha). Later, its meaning expanded to become the general term for "Liang Sha Chou", which encompasses both the open-work Liang gauze (Sha) and the plain-weave Liang satin (Chou). It is important to note that Liang Sha and Liang Chou are entirely different in terms of their weaving techniques.


XIANGYUNSHA SILK
NANSHA CULTURE



Dyeing and Finishing Step 19: Finished Product Fixed-Length Measurement

Process Positioning: Core quality inspection step before leaving the factory. After sunning, precise length measurement is performed for each piece of Gambiered Guangdong Silk to achieve:

✅ Finished product data archiving
✅ Shrinkage characteristics verification
✅ Basis for storage and logistics

Standardized Operating Procedure

Step
Operating Specification
Spreading the Greige Silk
Spread the finished Gambiered Guangdong Silk completely flat on even grassland to eliminate creases and tension, ensuring an accurate measurement baseline.
Warp-direction Measurement
Use a calibrated meter ruler to closely follow the fabric surface along the warp direction (lengthwise) of the silk piece. Measure in segments and sum to obtain the total length.
Dual-personnel Verification
The warehouse keeper performs the operation while the inspector simultaneously records the value, implementing a double-check to prevent errors.
Piece-end Marking Clearly mark the final length value on the piece end
 (starting end of the silk piece) as a permanent identification label.

Key Data: Shrinkage Patterns and Industrial Value

  1. Shrinkage Phenomenon: After the degummed/bleached greige silk undergoes the sunning process, irreversible length shrinkage commonly occurs.

  2. Shrinkage Formula: Finished Product Shrinkage Ratio = (Original Length of Degummed/Bleached Silk − Measured Length) ÷ Original Length of Degummed/Bleached Silk × 100%

    • Empirical Value: This shrinkage ratio ≈ the inherent shrinkage rate of the degummed/bleached silk (caused by gambier liquid penetration and fiber physical tightening due to sun exposure).

  3. Application Significance:

    • Provides pre-shrinkage compensation parameters for garment pattern making, ensuring stable clothing dimensions.

    • Enables reverse monitoring of sunning process consistency (abnormal shrinkage ratios indicate temperature/humidity control deviations).

Quality Control Notes:
⚠️ Measurement Surface: Must be performed on grassland/a flexible interface; hard ground will cause data distortion.
⚠️ Tool Management: Calibrate the meter ruler for accuracy before starting work each day; error must be ≤0.5%.
⚠️ Environment Recording: Record the temperature and humidity during measurement (e.g., 28°C/65% RH), as the shrinkage ratio is environmentally sensitive.



If you're intrigued by the intricate beauty of Gambiered Guangdong Gauze and wish to explore it further, we have a curated space just for that. Simply leave a comment below or send us a private message with "NanshaXiangyunsha" to find your way into our WeChat cultural community.

▲Wang Xuan, Xiangyunsha Culture Researcher
