马天尼 MUELLER-MARTINI Diamant MC 60 2010年
马天尼 Müller Martini Diamant MC 60
制造商：Müller Martini
型号：Diamant MC 60
年份：2010
RHE 621 Casing-in line with ‘AMRYS’ Pre-setting System.
AMRYS computer system for automatic make-ready with touch screen display
Equipped with:
Introduction belt
AS 620 Spine warm up section for hot-melt bound books for better rounding
GK 650 with 1st gluing & gauzing, 2nd gluing with paper lining, head & tail banding
EH 311 A-600 Casing-in station with automatic case feeding & Nordson hot-melt joint gluing
EP 680L joint forming and pressing unit with continuously variable temperature and
pressing pressure during joint forming.
BLSD 650D book stacker to
Technical specifications book line model RHE 621:
Product thickness: from 4 mm to 80 mm
Max book block format: 380 x 270 mm
Min book block format: 100 x 100 mm
Technical specifications casing-in unit:
Max cover format: 660 x 398 mm
Min format: 156 to 105 mm
Cover thickness: from 1 mm to 5 mm
Technical specifications book pressing and joint forming machine EP 680:
Max Mechanical speed: 3.720 cycles/hour
Max format: 300 x 390 x 80 mm
