| 外形尺寸(mm) | 额定负载(kN) | 极限转速(rpm) | 重量(Kg) | 型号 | |||||
| d | D | B | rs min | Cr | Cor | 脂润滑 | 油润滑 | (参考) | O&KAI |
| 10 | 35 | 11 | 0.6 | 8.2 | 3.5 | 15000 | 21000 | 0.053 | 6300 |
| 12 | 37 | 12 | 1 | 9.7 | 4.2 | 14000 | 20000 | 0.06 | 6301 |
| 15 | 42 | 13 | 1 | 11.4 | 5.45 | 13000 | 18000 | 0.082 | 6302 |
| 17 | 47 | 14 | 1 | 13.5 | 6.55 | 12000 | 17000 | 0.115 | 6303 |
| 20 | 52 | 15 | 1.1 | 15.9 | 7.9 | 11000 | 15000 | 0.144 | 6304 |
| 25 | 62 | 17 | 1.1 | 21.2 | 10.9 | 10000 | 13000 | 0.2193 | 6305 |
| 30 | 72 | 19 | 1.1 | 26.7 | 15 | 8000 | 10000 | 0.3498 | 6306 |
| 35 | 80 | 21 | 1.5 | 33.5 | 19.1 | 6800 | 8000 | 0.4542 | 6307 |
| 40 | 90 | 23 | 1.5 | 40.5 | 24 | 5800 | 7200 | 0.6394 | 6308 |
| 45 | 100 | 25 | 1.5 | 53 | 32 | 5000 | 6200 | 0.8363 | 6309 |
| 50 | 110 | 27 | 2 | 62 | 38.5 | 4400 | 5500 | 1.0822 | 6310 |
| 55 | 120 | 29 | 2 | 74.1 | 45 | 4200 | 5300 | 1.35 | 6311 |
| 60 | 130 | 31 | 2.1 | 85.2 | 52 | 4000 | 5100 | 1.7 | 6312 |
| 65 | 140 | 33 | 2.1 | 97.5 | 60 | 3900 | 5000 | 2.1 | 6313 |
| 70 | 150 | 35 | 2.1 | 111 | 68 | 3800 | 4800 | 2.5 | 6314 |
| 75 | 160 | 37 | 2.1 | 119 | 76.5 | 3600 | 5600 | 3 | 6315 |
