| Technical parameter | ||
| machine name | BL-1050S | BL-1050SS |
| max sheet size | 1050 x 750 mm | 1050 x 750 mm |
| min sheet size | 400 x 360 mm | 400 x 360 mm |
| max feeder pile height | 1500 mm | 1500 mm |
| max delivery pile height | 1400 mm | 1400 mm |
| max die cutting size |
1040 x 720 mm | 1040 x 720 mm |
| die cutting plate size | 1080 x 736 mm | 1080 x 736 mm |
| inner chase size | 1140 x 750 mm | 1140 x 750 mm |
| cutting rule height | 23.8mm or 23.6mm | 23.8mm or 23.6mm |
| stock range | 80~2000g/m² cardboard， | 80~2000g/m² cardboard， |
| thichness≦4mm corrugated paper. | thickness≦4mm corrugated paper. | |
| die cutting accuracy | ≤ ± 0.075 | ≤ ± 0.075 |
| Min.holding width | 8 mm（can do no grip） | 8 mm（can do no grip） |
| max die cutting speed | 7500 sheets/h | 7500 sheets/h |
| max pressure rigidity | 300 T | 300 T |
| air requirement | displacemen t0.36m³/min,dischage pressure:0.6-0.7Mpa | |
| power required | 380V/50HZ three-phase and four-wire | |
| overall power | 20 kw | 20.2 kw |
| net approx weight | 16 T | 16.2 T |
| overall dimension | 7300 x 4250 x 2350 mm | 7300 x 4250 x 2350 mm |
